Ball valves for gas, Venus Angle

Application fields:
The VENUS angle series is particularly recommended in gas installations (families 1°, 2°, 3° EN 437).

Threaded end connections:
• Standard male and female according to UNI ISO 7/1 (UNI ISO 10226).
• Art. 1072G304 M/F with T-handle 1/2" x 1/2".
• Art. 1073G334 M/M with T-handle 1/2” x 1/2”.

Operation devices:
Sluminium T-handle.

Available colours:
yellow.

All the valves comply with the regulation 2014/68/CE and are tested 100% on pneumatic seal with electronic control.

Features
Technical specifications
Dimensions
Sectioned

• The VENUS angle valve for gas is duty and is full bore.

Bore:
full.

Stem:
anti blow out.

Seats:
high resistance virgin PTFE.

Upper seal:
4 seals
1 PTFE ring- high pressure
2 anti-friction self-adjusting cone shaped seals, in PTFE - medium and low pressure
1 O-Ring - low pressure

• The VENUS series complies to the regulation (UE) 305/2011 CPR (Building Material)

Temperature limits:
for gas from –20°C to +60°C

Pressure limits:
for gas MOP5

Figures

Art. 1071

F/F with T-handle from 1/2” to 1”

Art. 1073

M/M with T-handle from 1/2” to 1”

Art. 1074

F/M with T-handle from 1/2” to 1”

Art. 1072G304

M/F with T-handle 1/2” x 1/2”

FOR FLEXIBLE GAS HOSES

Art. 1073G334

M/M with T-handle 1/2” x 1/2”

FOR FLEXIBLE GAS HOSES

Art. 1072

M/F with T-handle from 1/2” to 1”
